| Part Description Price Buy |
| PT2020 Hydrostatic Programmable Pump Controller |
| Comments |
| Pick the pressure range you need. * UK, EU, & AU Electrical cording also available. For more info, send us an email. |
• Industry-first automated controller for manual air-driven hydraulic pumps
• Automated pressure control for hydrostatic testing
• Plug’n play upgrade for any manufacturer's pneumatic intensifier pump
• Five pressure classes: 10,000 psi • 25,000 psi • 40,000 psi • 60,000 psi • 75,000 psi
• Easy-to-use touch screen interface
• Programmable test parameters
• Store and re-use many different test configurations
• Simply setup test, (or select from memory), hit "Start" and walk away
• Generates test certification reports
• Can be configured to run a second (fill) pump
• Automated pressure control for hydrostatic testing
• Plug’n play upgrade for any manufacturer's pneumatic intensifier pump
• Five pressure classes: 10,000 psi • 25,000 psi • 40,000 psi • 60,000 psi • 75,000 psi
• Easy-to-use touch screen interface
• Programmable test parameters
• Store and re-use many different test configurations
• Simply setup test, (or select from memory), hit "Start" and walk away
• Generates test certification reports
• Can be configured to run a second (fill) pump
| PT2020 Controller |
Ferguson
Engineering
 | |  | |  | |  | |  |
(805) 461-3920
High Pressure Equipment Company introduces
the first-of-its kind Automated Controller
System for air-driven high pressure hydraulic
pumps. The plug ’n play PT2020 is an easy-to-
use upgrade for any existing manual
pneumatic intensifier pump and is designed to
provide automated pressure control for a wide
range of hydrostatic testing. Operators simply
setup their test, press START and walk away…
the PT2020 will automatically run the test, give
a pass/fail reading and generate a test
certification report.
the first-of-its kind Automated Controller
System for air-driven high pressure hydraulic
pumps. The plug ’n play PT2020 is an easy-to-
use upgrade for any existing manual
pneumatic intensifier pump and is designed to
provide automated pressure control for a wide
range of hydrostatic testing. Operators simply
setup their test, press START and walk away…
the PT2020 will automatically run the test, give
a pass/fail reading and generate a test
certification report.
| THIS PAGE UNDER CONSTRUCTION |
Part# Kpsi Cordset* Cost
25N950 10 US $8,034
25N951 25 US $8,240
25N952 40 US $8,446
25N953 60 US $8,755
25N954 75 US $9,167
25N950 10 US $8,034
25N951 25 US $8,240
25N952 40 US $8,446
25N953 60 US $8,755
25N954 75 US $9,167
